Ka Band Bandpass Filter

Features: Low insertion loss, great rejection without tuning screws.

【Technical indicators】:

1.Working frequency: 30.50~31.00GHz

2.VSWR: 1.3:1 MAX

3.Insertion loss: 0.5dB MIN

4.Rejection: 70dB MIN@0~21.10GHz

5.Interface: WR34

6.Structure:

Ka Band Bandpass Filter

The role of filter is to filter out unnecessary radio frequency signals, while ensuring good passband characteristics. There are a wide variety of filters with different performances, and our company can quickly customize them according to the specific requirements of users.

Frequency range:  0.1~ 50GHz;

Function:  low-pass, high-pass, band-pass, band-stop;

Structural form:  waveguide type, cavity type, microstrip type, interdigital type, comb type, coaxial cavity type, Lumped/distributed, etc.;

Usage scenarios:  aerospace, navigation, radar, electronic countermeasures and satellite communications, etc.

Filters with special requirements can be designed, such as:

high altitude filter;

Ultra-high suppression filter;

ultra-wideband filter;

Ultra-narrowband filter;

TE01 mode low loss filter;

One-cavity multi-mode filter, etc.;

high power filter;

Linear phase filters, etc.
